SWRF Flanges Specification
Specifications | : | ASME B16.5 SWRF Flanges |
Size | : | 1/2"NB TO 24"NB IN |
Flange Face Type | : | SWRFe Face (FF), Raised Face (RF), Ring Type Joint (SWRF) |
Class / Pressure | : | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
Standard | : | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
SWRF Flanges Production Range
Stainless Steel
- Stainless Steel 304 SWRF Flanges
- SS 304L Raised Face SWRF Flanges
- UNS S30400 SWRF Flanges
High Nickel
- Inconel 600, 601 Raised Face SWRF Flanges
- Nickel Alloy 200 SWRF Flanges
- Titanium Grade 2 SWRF Flanges
Carbon Steel
- UNS K03504 SWRF Flanges
- LF3 SWRF Flanges
- ASME B16.47 Carbon Steel SWRF Flanges
Dimension Of SWRF Flanges
Size in Inch | Size in mm | Outer Dia. | Flange Thick. | Hub OD | Flange Length | RF Dia. | RF Height | Socket Depth | PCD | Socket Bore | No of Bolts | Bolt Size UNC | Machine Bolt Length | RF Stud Length | Hole Size | ISO Stud Size | Weight in kg |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
A | B | C | D | E | F | G | H | J | |||||||||
1/2 | 15 | 90 | 9.6 | 30 | 14 | 34.9 | 2 | 10 | 60.3 | 22.2 | 4 | 1/2 | 50 | 55 | 5/8 | M14 | 0.8 |
3/4 | 20 | 100 | 11.2 | 38 | 14 | 42.9 | 2 | 11 | 69.9 | 27.7 | 4 | 1/2 | 50 | 65 | 5/8 | M14 | 0.9 |
1 | 25 | 110 | 12.7 | 49 | 16 | 50.8 | 2 | 13 | 79.4 | 34.5 | 4 | 1/2 | 55 | 65 | 5/8 | M14 | 0.9 |
1 1/4 | 32 | 115 | 14.3 | 59 | 19 | 63.5 | 2 | 14 | 88.9 | 43.2 | 4 | 1/2 | 55 | 70 | 5/8 | M14 | 1.4 |
1 1/2 | 40 | 125 | 15.9 | 65 | 21 | 73 | 2 | 16 | 98.4 | 49.5 | 4 | 1/2 | 65 | 70 | 5/8 | M14 | 1.4 |
2 | 50 | 150 | 17.5 | 78 | 24 | 92.1 | 2 | 17 | 120.7 | 61.9 | 4 | 5/8 | 70 | 85 | 3/4 | M16 | 2.3 |
2 1/2 | 65 | 180 | 20.7 | 90 | 27 | 105 | 2 | 19 | 139.7 | 74.6 | 4 | 5/8 | 75 | 90 | 3/4 | M16 | 3.2 |
3 | 80 | 190 | 22.3 | 108 | 29 | 127 | 2 | 21 | 152.4 | 90.7 | 4 | 5/8 | 75 | 90 | 3/4 | M16 | 3.7 |
Price List SWRF Flanges
Price List | |
SWRF Flanges | US / Metric Ton (FOB Price) on request |
SWRF Flanges | US / Metric Ton (FOB Price) on request |
SWRF Flanges | US / Metric Ton (FOB Price) on request |
SWRF Flanges | US / Metric Ton (FOB Price) on request |
Available Stocks of SWRF Flanges
Preview | Products | UNS | DIN |
---|---|---|---|
Stainless Steel SWRF Flanges | UNS S30400, S30403, S31600, S31603 SWRF Flanges | 1.4301, 1.4306, 1.4401, 1.4404 SWRF Flanges | |
Duplex / Super Duplex Steel SWRF Flanges | UNS S31803, S32205, SAF-2205, S32750, S32760, SAF-2507 SWRF Flanges | 1.4462, 1.4410 SWRF Flanges | |
Copper Nickel SWRF Flanges | UNS C70600, C71500 SWRF Flanges | 2.0872, 2.0882 SWRF Flanges | |
Alloy Steel SWRF Flanges | UNS K41545, K90941, K11597, K21590 SWRF Flanges | 1.7362, 1.7386, 1.7335, 1.7380 SWRF Flanges |
Standard SWRF Flanges
American Steel SWRF Flanges Standard | |
Standard Code | Standard Name |
ANSI ASME SA-182 | SWRF Flanges |
ANSI ASME B16.5 | SWRF Flanges , sortj, soff, rfso flange |
ASME – B 16.36 | SWRF Flanges |
Application Of SWRF Flanges
We make sure that our every product is made of high quality raw material. We thoroughly test each and every product before dispatching it to our customers. one of the most trusted manufacturers and suppliers of fasteners and bolts which are applicable in various industries.
- Power Generation Industries
- Food Processing Industries
- Oil & Gas Industries
- Sugar Industries
- Petrochemical Industries
Testing Of SWRF Flanges
We known for its accurate and perfect dimensions. We thoroughly test all our products before shipping them to the customers. We carry out destructive as well as non-destructive tests on all our products.
- Eddy Current Examining
- Power Generation Industries
- Hydrostatic Analysis
- Positive Material Recognition
- Pitting Protection Test
Packing Of SWRF Flanges
We uses the most safest and the most effective ways of packaging for all types of deliveries. We pack our goods in various ways such as:
- Wooden Boxes
- Wooden Pallets
- Shrink-Wrapped
- Carton Boxes
- Wooden Boxes
